RaycoWylie Load Sensing Dynamometer Large

The large dynamometer is used to sense load on rope sizes from 1-1/8 inch up to 1-1/2 inch or 28mm to 38mm.  It has a rated capacity from 16,800 lbs up to 35,000 lbs.  This load sensor weighs approximately 75 lbs.  It is made with structured steel, has 3 sheaves each with double sealed ball bearing.  Mounting is completed via four mounting studs for mounting on the base section tip.  Optionally a swing arm can be installed for lattice crane applications or if an angle exists from the parallel to the boom.


Rayco Wylie History

Rayco Electronic System Limited was founded in 1979 (40 years) following the registration of the newly patented Range Limiting Device (Work area definition or zone access control) for lifting equipment such as lattice and telescopic cranes and excavators.  In 1933, The B&A Engineering Company Limited was founded on the release of the first UK – Factorate Inspectorate Approval Certificate for Cranes in order to commercialize the newly patented Load Moment Indicator (Rated Capacity Indicator/Limiter) invented by Major Hamilton Neil Wylie.

In 1994, Rayco increased its presence in the Heavy machinery Instrumentation Market by Acquiring B&A. Through the combined expertise, experience and passion of the employees, the Company was able to enhance its state-of-the-art technologies in line with the evolution of the machines and the market expectation.

RaycoWylie’s corporate headquarters are located in Québec City, Canada where you will find administration, manufacturing, engineering and research & development. All the offices including the head-office and the branch offices in the United Kingdom, United-States and new ones opened in Singapore in 2016 and Cairo, Egypt in 2017, have inventory and offer sales, services and technical support.

RaycoWylie is a world leader in heavy equipment monitoring systems. Its key areas of expertise lie in the development and installation of simple indicators or complex devices, easy to use and made to help our customers get their jobs done safely, efficiently and on time.

Among numerous applications, the company boasts state of the art rated capacity indicators specifically designed for offshore platforms, in compliance with classified zones. RaycoWylie excels in providing custom solutions for the ever demanding offshore industry, a field where they have been a major global provider for decades.
